SpringBoot/SpringCloud初探八（消息队列）

样例的消息队列采用kafka。相关软件（kafka软件和zookeeper软件）的安装见初探一（安装篇）。

注意：新的版本，kafka不采用sink和source（注解被弃用），而是改用supplier和consumer方式。

演示架构

左侧分支是publisher启动即发布一个主题关联的消息到stream-kafka，然后subscriber（服务本身）从队列获取该主题的消息并打印出来；

右侧分支是访问http://localhost:7888/request，则发布另外一个主题相关的消息到stream-kafka，然后subscriber A（另一个服务）从队列获取该主题的消息并打印出来。

一、Publisher

pom.xml

引入spring-cloud-stream和spring-cloud-stream-binder-kafka

    4.0.0

        org.springframework.boot
        spring-boot-starter-parent
        2.6.1


    com.abcd
    MessageStreamPublisher
    0.0.1-SNAPSHOT
    MessageStreamPublisher
    MessageStreamPublisher

        1.8
        2021.0.0



            org.springframework.cloud
            spring-cloud-starter-netflix-eureka-client



            org.springframework.boot
            spring-boot-starter-web



            org.springframework.cloud
            spring-cloud-stream



            org.springframework.cloud
            spring-cloud-stream-binder-kafka



            org.springframework.boot
            spring-boot-starter-test
            test


            org.springframework.cloud
            spring-cloud-stream
            test
            test-binder
            test-jar





                org.springframework.cloud
                spring-cloud-dependencies
                ${spring-cloud.version}
                pom
                import







                org.springframework.boot
                spring-boot-maven-plugin




application.yml

server:
  port: 7888

eureka:
  client:
    service-url:
      defaultZone: http://localhost:8761/eureka/

spring:
  application:
    name: msg_producer
  cloud:
    stream:
      function:
        definition: testSupplier;testConsumer;publishMsg
      bindings:
        testSupplier-out-0:
          destination: topic-hello
          content-type: text/plain
        testConsumer-in-0:
          destination: topic-hello
        publishMsg-out-0:
          destination: topic-user-request
          content-type: text/plain
      kafka:
        binder:
          brokers: localhost:9092
          #zk-nodes: localhost:2181
          auto-create-topics: true
          required-acks: 1

java

application实现supplier和consumer同体，即Publisher和Subscriber的URL和端口一样。

特别注意：方法返回采用Supplier和Consumer（java.util.function.Supplier/Consumer）

Application代码

@EnableEurekaClient
@SpringBootApplication
public class MessageStreamPublisherApplication {

    private static final Logger log = LoggerFactory.getLogger(MessageStreamPublisherApplication.class);

    public static void main(String[] args) {
        SpringApplication.run(MessageStreamPublisherApplication.class, args);
    }

    @Bean
    public Supplier testSupplier(){
        return () -> {
            String message = "www.test.com";
            log.info("Sending value: " + message);
            return message;
        };
    }

    @Bean
    public Consumer testConsumer(){
        return message -> {
            log.info("Received message: " + message);
        };
    }
}

以下service和controller实现supplier和consumer不同体（不同微服务实现）

Publisher Controller代码

@RestController
public class PublishController {

    @Autowired
    public PublishService publishService;

    @GetMapping("request")
    public void log(){
        publishService.log("userRequest");
    }
}

Publisher service代码

@Service
public class PublishService {

    private BlockingQueue mRequestList = new linkedBlockingDeque<>();

    public void log(String userRequest){
        mRequestList.offer(userRequest);
    }

    @Bean
    public Supplier publishMsg(){
        return () -> {
            String request = mRequestList.poll();
            System.out.println("publish msg: " + request);
            return request;
        };
    }
}

二、Subscriber A

pom.xml

引入spring-cloud-stream和spring-cloud-stream-binder-kafka

    4.0.0

        org.springframework.boot
        spring-boot-starter-parent
        2.6.1


    com.abcd
    MessageStreamSubscriberA
    0.0.1-SNAPSHOT
    MessageStreamSubscriberA
    MessageStreamSubscriberA

        1.8
        2021.0.0



            org.springframework.cloud
            spring-cloud-starter-netflix-eureka-client



            org.springframework.boot
            spring-boot-starter-web



            org.springframework.cloud
            spring-cloud-stream



            org.springframework.cloud
            spring-cloud-stream-binder-kafka



            org.springframework.boot
            spring-boot-starter-test
            test


            org.springframework.cloud
            spring-cloud-stream
            test
            test-binder
            test-jar





                org.springframework.cloud
                spring-cloud-dependencies
                ${spring-cloud.version}
                pom
                import







                org.springframework.boot
                spring-boot-maven-plugin




application.yml

server:
  port: 7889

eureka:
  client:
    service-url:
      defaultZone: http://localhost:8761/eureka/

spring:
  application:
    name: msg_consumer_a
  cloud:
    stream:
      kafka:
        binder:
          brokers: localhost:9092
          #zk-nodes: localhost:2181
          auto-create-topics: true
      bindings:
        receiveMsg-in-0:
          destination: topic-user-request
      function:
        definition: receiveMsg

java

Application代码

@SpringBootApplication
public class MessageStreamSubscriberAApplication {

    public static void main(String[] args) {
        SpringApplication.run(MessageStreamSubscriberAApplication.class, args);
    }

}

Service代码

@Service
public class SubscriberAService {

    @Bean
    public Consumer receiveMsg(){
        return request -> {
            System.out.println("SubscriberA receive msg: " + request);
        };
    }

}
